FE-EPMA — Model: JXA-iHP200

JXA-iHP200 equipped with field emission electron gun and integrated with enhanced features, satisfies the needs of research development & quality assurance in a variety of fields and achieves efficient operations from observation to analysis.

Enables observation of surface tissues and morphology and local trace element analysis.

JEOL FE-EPMA — Model: JXA-iHP200 — Electron Probe Microanalyzer (EPMA)

Manufacturer: JEOL — Japan

Overview

The Electron Probe Microanalyzer (EPMA) is an established tool for research, development and quality assurance across industries such as steel, automotive, electronic components and battery materials, and its applications continue to expand. In academia, EPMA is widely used in earth and planetary science and materials science, with growing contributions expected in advanced research on minerals, energy materials and new materials. What these users increasingly demand is an instrument that is simpler and faster to use - accessible to anyone - without compromising the high performance of microanalysis.

JXA-iHP200 equipped with field emission electron gun and integrated with enhanced features, satisfies the needs of research development & quality assurance in a variety of fields and achieves efficient operations from observation to analysis.

Effortless Setup

Holder Insertion with Auto Loading

Specimen insertion and acquisition of an optical image of the specimen holder (Stage Navigation image) are executed with a single click. The field for analysis can then be selected directly from the Stage Navigation image, so you can quickly find the target observation point.

Effortless Setup

Simplified Analysis

By combining the Auto Focus function of the optical microscope with a new, more accurate and faster generation of SEM Auto functions, any user can acquire high quality SEM images. Operability is further enhanced through the integration of SEM, EDS, WDS and optical images.

Live Analysis

Live Analysis enables elemental screening while you are still observing the specimen, so preliminary composition information is available during imaging.

Easy EPMA

With Easy EPMA, instrument settings are simplified for fast elemental analysis, allowing even novice users to operate the EPMA smoothly.

EPMA-XRF Integration and WD/ED Integration

EPMA-XRF integration allows analysis conditions of the EPMA to be set based on XRF data, while integration of WD and ED spectrometry shortens overall analysis time. A single click sets the analyzing-crystal combination based on the elements recommended from these techniques.

Simplified Analysis

Self Maintenance

Efficient Calibration with 18 Built-in Standard Specimens

A new spectrometer calibration function reduces the steps involved in periodic calibration and eliminates mis-operation by using 18 built-in standard specimens. Automated instrument calibration can be run overnight for greater efficiency.

Maintenance Notification

The maintenance notification function, provided through the Customer Support Tool, ensures that proper maintenance is carried out at the required timing.

Electron Gun

In-lens Schottky Plus Field Emission Gun (FEG)

The in-lens Schottky Plus FEG, which combines the electron gun and condenser lens, provides high resolution at low accelerating voltages, enabling high spatial-resolution SEM imaging and analysis at high magnifications. Ii also delivers a stable, small probe with large probe currents that are needed for fast trace-element analysis and for overnight analysis of multiple specimens. Furthermore, the optimization for EPMA enables large current analysis on the order of μA.

Max. probe current: 3 μA.

Probe current stability: ±0.3% / h; ±1.0% / 12 h.

Electron Gun

Related Option: Soft X-ray Emission Spectrometer (SXES)

The Soft X-ray Emission Spectrometer (SXES) is an ultra-high resolution spectrometer built around a newly developed diffraction grating and a high-sensitivity X-ray CCD camera. Like EDS it offers parallel detection, and it performs ultra-high energy resolution analysis of 0.3 eV (Fermi-edge, Al-L standard), surpassing the energy resolution of WDS.

Specifications

SpecificationsJXA-iHP200F
Detectable element rangeWDS: Be*¹ / B to U, EDS: Be to U
Detectable X-ray rangeDetectable wavelength range with WDS: 0.087 to 9.3 nm
Detectable energy range with EDS: 20 keV
Number of spectrometersWDS: Up to 5 selectable, EDS: 1
Maximum specimen size100 mm × 100 mm × 50 mm (H)
Electron GunSchottky Plus Field Emission Gun (FEG)
Accelerating voltage1 to 30 kV (0.1 kV steps)
Probe current range1 pA to 3 µA
Probe current stability± 0.3% / h, ± 1.0% / 12 h*²
Resolution (Secondary electron image)2.5 nm
For Analysis:
20 nm (10 kV, 10 nA)
Scanning image resolutionMaximum 5,120 × 3,840
Notes*¹ With analyzing crystal for Be analysis.
*² Room temperature variation: less than ± 0.5 ℃
